HICM150G series
HICM150G series
HiTRON HICM150G series is a medical AC DC open frame power supplies, delivers 150W of output power and accommodate the universal input voltage range 90 – 264 VAC. HICM150G series is suitable for installation in fanless medical devices such as monitoring, imaging, therapy and other portable equipment.
Download
Add to inquiry
Product Description
- 5x3 inch AC-DC power supply
- 150 W Convection/200 W Forced-cooled
- Single Output from 12V to 48V with 5V fan cooling
- Up to 94% high efficiency
- Wide operating temperature -20°C to +70°C
- Medical and ITE application
- Class I and Class II applications
- U-Bracket or Box format optional
Features
The HICM150G series is a 5x3 inch AC-DC power supply. It provides 150W capacity with convection cooling and 200W with forced cooling, meeting varying requirements. The power supply offers a single output voltage range from 12V to 48V and includes 5V fan cooling for efficient temperature control. With up to 94% efficiency, it optimizes energy consumption, supporting environmentally friendly practices and reducing operational costs. Designed to perform reliably in a wide temperature range of -20°C to +70°C.
